Swing Spindle Cnc Router With Atc Tool Changer

The 1325 Swing Spindle Cnc Router With Atc Tool Changer can automatically change tools to work, reducing labor input. The machine can quickly change tools for automatic processing, which improves the processing speed. The machine working area is 1300x2500mm, and vacuum work  table and LNC control system to ensure fast and accurate processing.



• The machine bed is welded with 6MM steel pipes, with multiple supports in the middle, and the structure is stable and does not deform.
• The gantry is reinforced with steel plates to reduce vibration during work and achieve high processing accuracy.
• The 9KW high-power air-cooled spindle can automatically change tools and can swing 180 degrees.
• The Y-axis is driven by two motors, with stable movement and no offset during processing.
• The Swing Spindle Cnc Router With Atc Tool Changer uses servo motors movement, which is fast and more stable.
• Use vacuum work table, which is fixed by air adsorption, and can also selecte an aluminum work table.
• The LNC control system from Taiwan, with stable system operation and automatic input path processing.
• The three axes use HIWIN guide rails, which are stable and fast.
• The Z axis uses TBI's ball screw drive, which has high processing accuracy.
• You can also use a rotating axis to process 3D/4D models.





● Working area ：1300mmx2500mmx200mm

● XYZ travel positioning accuracy:  ≤0.01mm
● XYZ repositioning positioning accury:  ≤0.025mm
● Table surface:  Vacuum work table
● Drive system X-Y axis: Guide rails and rack
● Spindle:  9KW air-cooled spindle,swing and atc change tools

● Spindle speed: 0 – 24,000 RPM

● Collet type: ER20

● Max velocity: 50m/min

● Max working speed: 25m/min

● Work mode: Servo motor

● Working voltage: AC220V/380V

● System: LNC control system(optional  SYNTEC system)

● Net / Gross weight: 1600kg / 1800kg





Design

Processing 3D or 4D molds, aviation molds, architectural molds, automotive molds, reliefs, flat engraving, etc.

Woodworking

Processing furniture and furniture decorations, other wooden artworks, etc.

Manufacturing

Enterprise manufacturing, home use, handcraft enthusiasts, etc.

other

The Swing Spindle Cnc Router With Atc Tool Changer machine use wide , and can be used in any industry. Please consult us details.













Jinan Hopetool CNC equipment Co.ltd. is a professional company specializing in developing and manufacturing CNC router , co2 laser machine,fiber laser cutting machine ,digital cutting machine.After 14 years' hard work, our machines have been exported to more than 80 countries, and we have established regular business relationships with many distributors from many countries.



Q: Do you accept OEM/ODM?
A: Yes, we can make the machine according to your special requirements.

Q: What is your minimum order quantity?
A: Our minimum order quantity is 1 set.

Q: Can I be your agent in our country?
A: Yes, please contact us for details.

Q: When is your delivery time?
A: Our delivery time for loading one container is 20 days.

Q: Do you have good after-sales service?
A: Yes, our after-sales service is 24*7

Q: I also purchased other goods from other suppliers, can you help me ship them together?
A: Yes, we are very happy to help.
