Woodworking Cnc Router



woodworking cnc router 1325 Cnc Router Machine For Wood And MDF is a multifunctional CNC equipment is Water cooling spindle, high precision, long life time, steady working, easy to start up

The woodworking cnc router 1325 Cnc Router Machine For Wood And MDF body is strong, rigid, high precision, reliable and durable.

Adopt imported high-precision rack, which has smooth movement and ensures the high precision of the machine tool.

High quality Taiwan imported linear guide has much longer life 10 times of life-time than round guide; It is stable and hard to distort.

woodworking cnc router  1325 Cnc Router Machine For Wood And MDF Using well known domestic brands of water cooling brushless spindle, low noise, and strong cutting ability, to ensure the long time working.

1530 Cnc Engraving Machine For Wood uesing high performance driven motor to ensure that the machines high speed and accuracy.

The 1530 Cnc Engraving Machine For Wood DSP A11 control system is a very popular control system with high quality.

Breakpoint specific memory, power outages continued carving, processing time forecast, and other functions to ensure that accidental processing.







Performance parameter





Description	parameter
XYZ working area	1300*2500*200mm
X,Y,Z Traveling Positioning Accuracy	±0.03/300mm
X,Y,Z Repositioning Positioning Accuracy	±0.03mm
Lathe Structure	Welded Strucutre
X, Y Structure	Gear Wheel Transmission, Shaft Linear Bearings
Z Structure	Ball Screw, Shaft Linear Bearings
Max.Consume Power	20KW
Max.Speed	0-60000mm/min
Max.Working Speed	0-25000mm/min
Spindle Speed	0-24000RPM
Working Mode	Servo system
Working Voltage	AC380V/50/60Hz , 3PH
Control System	DSP System
Interface	Internet line
Flash Memory	512M
Collet	ER32
X,Y Working Delicacy	<0.01mm
Software	Type3 software, Wentai software,Artcam software
Running circumstance	Temperature: 0°C~45°C, Relative humidity: 30%~75%
Packing Size	3100x2300x1900 mm
Net Weight	1200KG



Working Samples



Success Case

This 1530 Cnc Engraving Machine For Wood is widely used in furniture processing industry, home decoration, wood working decoration, doors manufacturing,wood art craft and so on. it is also widely used in processing for single lines, milling,3D embossing, cutting and engraving etc.

Efficient manufacturing of wooden products, advertising billboard, acrylic cutting, letter mold form-ling and mass cutting. Also the machine can engrave on iron, brass, aluminum, plastic and wood boards and other non-metal materials.
